NES 833 Nickel Aluminum Bronze Rods

100 Kilogram (MOQ)

Business Type Manufacturer, Supplier, Trader
Material Aluminium
Shape Round
Feature Corrosion Proof, Excellent Quality, Fine Finishing
Click to view more

Preferred Buyer From

Location Anywhere in India

Product Details

Type
Aluminium Bronze Rods
Country of Origin
India

We are a leading and well recognized names in the field of offering quality finished range of NES 833 Nickel Aluminum Bronze Rods that are as per BS:2872 CA-103, 104, ADM1076D, IS:10569/83, BS:1400AB1, AB2, IS:305 AB1. Also meeting the specifications as per IS 10569/05 NR. EQUIVALENT SPEC. BS 2872/86 CA103, ASTMBC62300, these are made available in annealed finish in sizes of 6 to 15, 15 to 50, 50 to 80 and 80 and above. These bronze rods have excellent capacity to be cold and hot formed and have machine-ability rating of 50%. Further, the rods have Forge-ability rating of 75 %, fair suitability for brazing and good welding capability.

Being corrosion resistant & non sparking alloy, some of the application uses of these bronze rods include

  • Oil refinery
  • Valves & fittings
  • For worm gears
  • Valve stems
  • High pressure valves

Yes! I am interested


Specifications:

Aluminum Bronze ASTM B 111 C60800
ASME SB 111 C 60800
EN 12451 CuAl5As
CW200G

Chemical Requirements

Copper Remainder
Aluminium 8.5 to 11.0%
Iron 4.0 to 6.0%
Nickel 4.0 to 6.0%
Manganese 0.50% max
Tin 0.10% max
Zinc 0.40% max
Silicon 0.10% max
Total Imp. Excl. Mn 0.50% max

Physical Properties

Condition Size T.S. MPa EL% Min
Annealed / As Manufactured 6 to 15
15 to 50
50 to 80
80 & above
700
700
680
650
10%
12%
12%
12%

Fabrication Properties

Capacity for being
Cold formed Poor
Hot formed Good
Machinability rating 0.3
Forgeability rating 0.75
Suitability for soldering Poor
Suitability for Brazing Fair
Suitability for welding Good

Uses

Excellent for corrosion resistant, Highest strength,Good wear and heat resistance, Like marine pump hardware & bearings, Valve guides & seats, Nuts, Shaft, Bolts & Threaded Parts for Ship building & power generation industries.
